Magnetrol AMETEK Modulevel Pneumatic Level Controller
Listing ID:
ASSK-63657
Connection Status:
Disconnected
Notes:
Details
| Field | Detail |
|---|---|
| Manufacturer / Brand | Magnetrol / AMETEK Level Measurement Solutions |
| Supplier | Vanko Analytics Limited |
| Product Type | Pneumatic Modulevel displacer level controller / transmitter assembly |
| Part Number / Model | XP65-2P5C-PCA |
| Documentation Description | Pneumatic Modulevel Displacer Level Controller / Transmitter Assy with Displacer/Float 48 in. |
| Model Code | P65 |
| Mounting / Chamber Arrangement | Top mounted with carbon steel flange; external cage side/side mounting location |
| Chamber Style | Flanged top chamber, 600# |
| Chamber Material | Carbon steel |
| Process Connection | 1-1/2 in. 600# RF ASME B16.5 flange, carbon steel A105 |
| Vent / Drain | 1/2 in. NPT vent and drain connection |
| Specific Gravity / Temperature Rating | 0.55–1.09 SG, 200°C / 400°F maximum |
| Level Range / Displacer Length | 1200 mm / 48 in. |
| Pneumatic Controller Code | PCA |
| Controller Material / Enclosure | Aluminum controller, NEMA 1/2/3/3R |
| Pneumatic Connections | Two 1/4 in. NPT pneumatic connections |
| Controller Type | Single function |
| Controller Function | Transmitter |
| Controller Mounting | Integral |
| Controller Action | Direct acting |
| Controller Output / Supply | 0.2–1.0 bar / 3–15 psig output; 1.4 bar / 20 psig supply |
| Packaging | Secured long crate, stored indoors; not opened to avoid compromising packaging |
Typical Application
Pneumatic Modulevel displacer level controllers are typically used for industrial liquid level measurement and control in tanks, pressure vessels, separators, process drums, and similar equipment. This configuration is especially relevant where the site uses a pneumatic control loop, since the controller is documented as a single-function transmitter with 3–15 psig pneumatic output and 20 psig supply.
